Technical Parameters
| Model | LK-IP20 | LK-IP30 | LK-IP50 |
| Laser Power | 20W | 30W | 50W |
| Laser Wavelength | 1064nm | ||
| Q-frequency | 20KHz~80KHz | ||
| Divergence | 0.3mard | ||
| Marking Range | 10*10mm to 300*300mm | ||
| Minimum Line Width | 0.02mm | ||
| Minimum Character | 0.15mm | ||
| Marking Depth | 0 ~0.5mm | ||
| Engraving Line Speed | ≤7000mm/s | ||
| Repeatability Accuracy | ±0.001mm | ||
| Beam Quality | M2:1.2~1.8 | ||
| Marking Format | Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date,Batchnumber,Serialnumber,Frequency,etc. | ||
| Graphic Format Supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. | ||
| Working Voltage | 220V±10%/50Hz/4A | ||
| Unit Power | <0.5kw | ||
| Use of the Environment | Clean and Dust Free or Dust less | ||
| Working Condition:Humidity | 5%-75%,Free of Condensed Water | ||
| Laser Module Life | >100000 hours | ||
Marking Sample
Application Industries:
Mobile phone keypad, plastic translucent keys, electronic components, integrated
circuits (IC), electrical appliances, communication products, sanitary ware, tools,
accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking
utensils, stainless steel products and other industries.
Application Materials:
Metals (including rare metals), engineering plastic, electroplating material, coating
material, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel
titanium, cooper and other materials.
Packing &Shipping
1.Standard plywood case, its compressive strength and bearing quality is better.
2.the board area is bit, the soil structure is good, it is better in leakproofness and waterproof.
3.when importing, the plywood case is with fumigation-free, the procedure is simple.
4.Delivery Detail: within 3-5 days after received your payment
Our Service
1.One year quality guaranty, the machine with main parts(excluding the consumables)shall be changed free of charge when if any problem during the warranty period.
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.24 hours on line service each day, free technical support.
5.Machine has been adjusted before delivery
Company Profile
Shenzhen Leikang Laser Technology Co.,Ltd .was established in 2007,which specialized in laser marking / welding/ cutting machine for 10 years , we have high-class of technical development team that cooperate with Huazhong University of Science & Technology , We developed many high quality products such as : Laser manipulator mold welding machine ,CO2 laser marking machine and Automatic laser welding machine etc. They are widly used in electric component , gift, communicaton equipment , electirc appliance, construction material ,package of food and medicine ,pvc materials , IC integrate circuit, craftwork, semiconductor etc.
The products are exported to many countires such as Australia , Pakistan, India, America........, we provide high quality and excellent after sales service to our customers
