Fiber Co2 Uv 50W Mini Portable Laser Marking Machine
1. Model: Fiber Laser Marking Machine
1. Model: Fiber Laser Marking Machine


1. Model: Fiber Laser Marking Machine
2. Applicable materials:
Applicable various metal, such as silver, alloy, aluminum, stainless steel, copper etc, and some non-metal materials, such as
PVC,PC, black acrylic.
3. Applicable industry:
They are widely applying for electronic, jewelry, automobiles, communication products, plastic buttons, IC etc.
1. Model: Fiber Laser Marking Machine
2. Applicable materials:
Applicable various metal, such as silver, alloy, aluminum, stainless steel, copper etc, and some non-metal materials, such as
PVC,PC, black acrylic.
3. Applicable industry:
They are widely applying for electronic, jewelry, automobiles, communication products, plastic buttons, IC etc.
NO. | ITEM | DATE |
1 | Laser power | 20W 30W 50W 100W |
2 | Laser wavelength | 1064nm |
3 | Beam quality | M2<2 |
4 | Control software | Ezcad (provided) |
5 | Marking depth | ≤0.3mm |
6 | Cutting depth | ≤1mm(30W 50W 100W mark 1-3mins repeatedly then can cut) |
7 | Marking speed | ≤7000mm/s |
8 | Minimum line width | 0.01mm |
9 | Minimum character | 0.5mm |
10 | Marking Size | 110 * 110mm ( 75mm 200mm 300mm optional ) |
11 | Electric power | <500W |
12 | Working voltage | 110/220V ± 10%, 50/60HZ |
13 | Cooling way | Air cooling |
14 | Ambient operating temperature | 15 ° C - 35 ° C |
15 | Graphic file format | PLT, DXF, AI, BMP, JPG |
16 | Machine weight | 39 |
17 | Machine size | 56L * 55W * 72H (cm) |
18 | Packing | Plywood box |
