Fiber Laser Marking Machine Laser Pattern Marking Machine Fiber Laser Engraving Machine
1) Portable style, small size, easy to transportation. The equipment can work with customized automatic matching system.
2) Adopt high-series QE model laser source, superior laser beam, stable performance and high reliability.
3) The machine can work with all metallic materials, such as gold, silver, copper, stainless, aluminum, ect; and some non-metallic materials.
BAOKUN Laser Marking Machine for Metal & Plastics. It can work with most metal marking applications, such as Stainless Steel, Brass, Aluminium, Steel, Iron etc, and can also mark on many nonmetallic materials, such as ABS, Nylon, PES, PVC, Makrolon, etc.
1) Electronic Components: Resistors, Capacitors, Chips, Printed Circuit Boards, Computer Keyboard, etc.
2) Mechanical Parts: Bearings, Gears, Standard Parts, Motor, etc.
3) Instrument: Panel Board, Nameplates, Precision equipment, etc.
4) Hardware Tools: Knives, Tools, Measuring Tools, Cutting Tools, etc.
5) Automobile Parts: Pistons and Rings, Gears, Shafts, Bearings, Clutch, Lights, etc.
6) Daily Necessities: Handicrafts, Zipper, Key Holder, Sanitary Ware, etc.
1) Long lifespan of fiber laser source: 100 000 - 200 000 hours.
2) Low consumption: <450W, more economical and environmental.
3) High Speed: 7000mm/s, faster than traditional machines.
4) Superior Laser Beam: The definition is 1 micron, 10 times as traditional products.
5) No Consumables: One marker can work for more 8-10 years without any consumables.
6) The fiber laser beam comes out from the fiber laser source directly, no need to adjust the laser beam path.
7) High-precision and high-speed scan head, with good seal, capable to prevent dust and water, small volume, compact.
8) High-stability controller, USB interface, swift and stable transmission, route optimization, easy operation.
9) Strong Compatibility: PLT, BMP, JPG, TTF, DXF, SHX, AI and other format files output from CorelDraw, AI, PS, AutoCAD, Solidworks etc..
10) Integrated Air Cooling System: Better cooling effect than water-cooling effect in YAG laser, no maintenance.
|Power||20W / 30W / 50W / 100W / 120W|
|Standard Marking Area||150mm*150mm|
|Optional Marking Area|| 70*70mm / 100*100mm / 200*200mm / 300*300mm |
|Minimum Line Width||0.015mm|
|Fiber Laser Source||Raycus from China|
|Scan Head||Galvo Tech from China|
|Controller (software)||JZC Controller & EzCAD Software from China|
|Lifespan of Fiber Laser Module||100 000-200 000 hours|
|Beam Quality||M2 <1.6|
|Focus Spot Diameter||<0.01mm|
|Output Power of Laser||10%~100% continuously to be adjusted|
|Output Frequency of Laser||30KHz~60KHz continuously to be adjusted|
|Power Stability (8h)||<±1.5%rms|
|System Operation Environment||Windows XP / 7 / 8 / 10 -32/64bits|
|Cooling Mode||Air cooling|
|Temperature of Operation||0~40|
|Voltage||220V / 50HZ / 1-PH or 110V / 60HZ / 1-PH|
|Optional (Not free of charge)||Rotary Device, Moving Table, Lens, Fume Purifier, other customized Automatic Matching|
