Portable micro jewelry laser marking machine mini jewelry laser marker
Feature

Permanent marking: Laser marking is a permanent marking. It won't fade, run or become less discernable as time passes like traditional marking including ink jet, hand engraving, dot-peen marking.
Long service time: Fiber laser model has a over 100,000 hours working life. Almost no maintenance during this period.
Easy to operate: The portable laser marking machine support almost any Windows-based software like Coreldraw, AutoCAD, Photoshop. No need to adjust Q-switch easier than YAG diode marking machine.
High precision: 0.0025mm re-position accuracy. Minimum line width for the portable laser marking machine is 0.01mm.
Non-contact process: Won't cause mechanical extrusion or mechanical stress to materials. Laser beam won't move the work piece.
Portable: Small footprint, easy to move and transportation. The size for thr portable laser marking machine like a computer case.

Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker
Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker


Technical Parameters

Technical Parameters

 Type

cylinder Fiber laser marking machine

 Power

 20W 30W

 Laser Wavelength

1064nm

 Marking Area

110*110mm, 70*70mm

 Marking Depth

≤1mm

 Marking Speed

7000mm/second

 Minimum Line Width

0.01mm

 Minimum Character

0.15mm

 Repeated Precision

±0.002mm

 Life-span of Fiber Laser Module

100 000hours

 Beam Quality

M2 <1.5

 Laser Wavelength

1064nm

 Output Power of Laser

10%~100% continuously to be adjusted

 System Operation Environment

Windows XP / W7--32/64bits / W8--32/64bits

 Cooling Mode

Air cooling--Built-in

 Temperature of Operation Environment

15ºC~35ºC

 Power Input

110/220V ± 10% /,50/60HZ

 Power Requirement

<500W

 Communication Interface

USB2.0

 Machine Dimension/with package

65 (L) * 44(W) * 43 (H)cm

 Net Weight/gross weight

30KG/45kgs

 Optional (Not free of charge)

Rotary Device

Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker
Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker

Application Materials
The portable laser marking machine is widely used to 3C products, computer , watches, wristband ,phone ,hardware, stainless steel , many kinds of metal tools and other industries, and it can mark on the surface of many kinds of metal materials( stainless steel, high speed steel, alloy steel, iron, aluminum and aluminum alloy, etc ) and parts of non-metallic materials,such as ABS, PC,PVC,etc.

Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker
Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker


Packing& Delivery
1.Standard plywood case, its compressive strength and bearing quality is better.
2.the board area is bit, the soil structure is good,  it is better in leakproofness and waterproof.
3.when importing, the plywood case is with fumigation-free, the procedure is simple.
4.Delivery Detail: within 3-5 days after received your payment


Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker



Our service
1. 24hours Technical support by Email or Calling.
2. English manual and CD video for machine using and maintaining.
3. Hardware: 1 years for machine,
   Software: Whole life on update for free.

4.Maintenance and technological support: Whole life.
Portable Micro Jewelry Laser Marking Machine Mini Jewelry Laser Marker
Contact us



Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
