20w fiber laser engraving for gold silver metal ring and necklace portable fiber laser marking machine
Model | SKD-20FP SKD-30FP SKD-50FP SKD-100FP | ||
Laser Power | Wuhan Raycus brand optical fiber laser generator | ||
Work size | 110x110mm 200x200mm 300x300mm | ||
Interface | USB | ||
Cooling type | air cooling | ||
Minimum Line Width | 0.01mm | ||
Minimum Character | 0.15mm | ||
Marking Depth | 0~0.5mm | ||
Engraving Line Speed | ≤7000mm/s | ||
Repeatability Accuracy | ±0.001mm | ||
Beam Quality | M2:1.2~1.8 | ||
Graphic Format Supported | bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc. | ||
Voltage | 220v/single or 380v/3phase or as customer needed | ||
Unit Power | <0.5kw | ||
Working Condition:Humidity | 5%-75%,Free of Condensed Water | ||
Operating system | Ezcad | ||
Interface | USB | ||
computer | can choose or not | ||
package | Export wooden box | ||
G.W | 65kgs |
